POWERING THE FUTURE, HARNESSING THE UNIQUE PROPERTIES OF DIAMOND

Among the most versatile supermaterials on earth, diamonds are uniquely suited to advance technological discovery. At WD, our renowned team of PhDs, scientists and engineers focus their research and development on breakthrough diamond applications to solve the world's most critical challenges. Pushing beyond form factor restrictions of the past, we provide cutting-edge diamond solutions for the future — reducing reliance on fossil fuels, powering quantum technologies, accelerating telecommunications reinvention, and democratizing clean air and water. Through power and purpose, WD stays true to our legacy of disruption.

The  future's most important supermaterial.

Made from pure carbon atoms tetrahedrally bonded in a crystalline structure, diamond is the only material — natural or engineered — to deliver unique physical and atomic properties that can be used to solve key technical challenges across industries.

HIGH STRENGTH

THERMAL EXPANSION

LOW FRICTION COEFFICIIENT

SOUND PROPAGATION

EXTREME HARDNESS

THERMAL CONDUCTIVITY

CHEMICAL STABILITY

BROAD OPTICAL TRANSPARENCY


WE ARE USHERING IN THE DIAMOND AGE

JOIN US IN FUELING THE INNOVATION OF TOMORROW

Image by Steven Binotto

EV

Reducing the reliance on fossil fuels and democratizing access to new electric technology

QUANTUM

Developing device solutions that power efficient, scalable quantum computing

Communication Tower

TELECOM

Enabling next generation,
high-performance systems

for a more connected world

Water

STERILIZATION

Creating effective, lifesaving systems that expand availability of clean air and purified water

Image by Fakurian Design

CVD diamond grades.

Through major form factor advances, WDAM creates scientific-grade diamond material to precise order specification, spanning edge lengths, surface orientations, and final material preparation.

01_ Quantum

Isotopically pure, highly polished diamond wafers that  feature nitrogen vacancy (NV) centers, for use in next-gen research and advanced technologies

02_ Conductive

Boron-doped, rough-cut to semi-polished wafers for use in nano-indentors, deep-UV LEDs and other semi-conductor devices, among other conductive diamond applications

03_ Intrinsic

Ultra-pure, undoped diamond material in rough cut or semi-polished form for use in sensitive thermal substrate and optical applications, including synchrotrons

04_ Optical

​Semi- to- fully-polished low-defect diamond material, for use in a variety of applications including high-power electronics and surgical blades

Diamond Wafers
Contact us

Looking for custom diamond solutions?

Reach out today to connect with our industry-leading team of engineers and scientists.
